Pok3r

Mechanical Gaming Keyboard Vortexgear Pok3r 60%, ABS Double Shot Translucent Keycaps, RGB LED Backlit, 61 Keys (Aluminium CNC Casing) (Cherry Mx Silent Red, White) 4.2 out of 5 stars 73 Currently unavailable. A few weeks back, /u/MavigoYT posted their Corsair Strafe RGB with some amazing translucent keycaps. After seeing their post, it inspired me to pick up a set for myself. I got them in today, and they look stunning on my Pok3r RGB.

The Pok3r is a keyboard manufactured by Vortex with a compact 60% layout. It was released on the 8.5.2015 and supersedes the Poker II. Picture Black / Grey. (normally $199) The Vortexgear RGB POK3R is a premium 60% size mechanical keyboard featuring Cherry MX Brown switches, RGB backlighting, double shot ABS keycaps, USB key rollover, US QWERTY layout and more. It's miniature size makes it ideal for those who have strict space limitations or are looking for an ultra portable keyboard that. POK3R User manual Description: The Vortexgear POK3R is the perfect solution for limited spaces in situations. Built up 3 kinds of layout, it features individually programmable keys with 3 layers customization options, all easily set through what you want. Main Specification: 1. Page 2 Programming Instruction Note: The POK3R built in 4-layers.

Software

There are no software drivers for the Vortex POK3R V2, with all functionality hardware based. As such, I have chosen to combine this section with the performance section below. Note that Vortex has an online configurator they call MPC, which is available on their website. However, Vortex says the more budget-minded POK3R V2 will not get MPC support, which is a shame because it makes programming the keyboard a lot more user-friendly.

Performance

The Vortex POK3R V2 comes configured to support 6-key rollover USB out of the box, which tested successfully using Aqua's test. Weirdly, there is no option to even switch to NKRO for those who need it, although this is admittedly not really a factor with the 60% form factor adopted here. No key chatter was detected on all the keys using Switch Hitter. The image above also shows what the base layer on the keyboard is pre-programmed to as far as dedicated keys go. As with just about any keyboard these days, there is no right Windows key, having being substituted by an Fn key instead. Also, as with other Vortex keyboards, the menu key on the right of the space bar is instead their 'Pn' key for programming the keyboard.

When first connected, the keyboard lights up in a static white color for all keys, which helped test color fidelity since RGB LEDs have a hard time depicting white, and it was one of the more accurate whites here, which is always good to see. As expected from previous findings, the keycaps are not really backlit, and we only see the lighting seep through the sides and into any common spaces between keycaps. As seen above, the white base keycaps are better illuminated here relative to the dark gray ones. In a separate test via one of the preset multi-colored options, I tested for light bleed, and it was definitely present at the common edges because of the floating keycaps, but not offensively so.

Customizing backlighting on the keyboard is all done via onboard controls, and I have included the relevant section of the manual given the lack of an online manual as this is written. For those with experience with a recent Vortex RGB keyboards, the instructions above will be very familiar and bring with it either a sense of relatable relief or dread, and not much in between. There are definitely fans of this specific onboard control scheme using Vortex's Pn key and their palette mode, of which we have 61 colors using all 61 keys on the POK3R V2, and R/G/B per-channel brightness in 10 steps (including off) to allow for more granular backlight (or side lighting, as is the case here). Pre-programmed effects can be toggled through for those wanting a light show, of which there are not many, and there are custom modes for per-key lighting control to allow for, say, only WASD keys to be lit up during gaming if needed.
Here are some of the lighting effects demonstrated, including a color cycle, aurora, and rainbow wave mode, all making full use of the hardware onboard. The transition animation is smooth, and the effect is a good demo to also ensure the keyboard is powered on and working properly. You will not get a lot of effects compared to the more mainstream offerings with software drivers, so keep that in mind if it is an important factor for you.

Aside from the base layer, which has legends printed on the keycaps for easy identification, there are three other layers for custom programming. Layers are accessed as with other Vortex keyboards, in that Pn + N/M toggles through layers 0–3. Layer 0 is the default layer, and the left LED under the space bar is off to signify this. It turns red, green, or blue to indicate whether you are in layer 1, 2, or 3 respectively. Vortex has additionally pre-programmed the Fn+ layer for added functionality as seen above. This is absolutely key on a smaller form factor keyboard such as the POK3R V2, and I like the logical choices Vortex has made. The main problem is that the keycaps do not show these pre-programmed functions as front-printed legends similar to before with their other small form factor keyboards. This, combined with the lack of a printed manual and current absence of an online variant means users are left to guess at what to do.
The other functions are for the macro functionality, which remains as powerful as with other Vortex keyboards from recent years. Indeed, there are custom modes for recording keystrokes as expected, but onboard controls also allow for the addition of keystroke delays, multimedia functions, and even complete re-assignment if you want to go with, say, a Dvorak layout instead of QWERTY for typing. As expected, you can also reset the current keyboard layer or all layers if you messed up and want to start from scratch. This is definitely where Vortex's MPC support would have been handy, especially for power users wanting to quickly customize powerful macros on layers 1–3.
Overall, using the POK3R V2 will take time and effort for most users. This is especially true for those used to the 104/105-key full-size form factor their entire life, but it is definitely worth it if you know you will benefit from the smaller form factor. The ergonomic benefits are logical for most people, with the mouse in a more natural position closer to the keyboard. Less finger travel can also be very efficient, but only if you have set up the keyboard with the keystrokes of your desired layout on the base layer and are comfortable with using the other layers as needed. I usually take a minimum of a week to get re-accustomed to such form factors after weeks of testing TKL/full-size keyboards and found myself getting used to the POK3R V2 within five days of typical use to where I was typing at my usual speed already. I did find myself often comparing it to the 65% Ducky One 2 SF we recently reviewed, especially since it has dedicated arrow keys and then some, so perhaps that is an alternative you may want to consider as well.

The Vortex POK3R V2 keyboard only comes with the Cherry MX Low Profile RGB Red switches. This switch, as Cherry puts it, 'has a very shallow profile and is specially designed for flat desktop applications as well as notebooks'. As seen above, it attempts to best replicate the typing feel of the popular Cherry MX Red switch by using a steeper force-travel diagram. We have a 1.2 mm rated actuation distance with 3.2 mm total travel as opposed to the respectively more typical 2.0/4.0 mm setup. Actuation force is rated the same as for the Cherry MX Red at 45 cN, although the heavier spring means you need to apply more force to fully bottom out. You can find more information on the official product page, and these are among the smoothest linear switches Cherry has ever made. The flat, low profile keycaps have an impact on it as well, and not necessarily positively, at least for me.
As always, the sound of a keyboard is based on more than just the switch type. So when comparing sound clips, consider the keyboard as a whole. In this case, I have provided above an example sound clip of me typing on the Vortex POK3R V2 keyboard sample at ~105 WPM as it comes out of the box with the Cherry MX Low Profile Red RGB switches. For context, you can find sound clips from other keyboards here, including those with linear switches. I did bottom out often given the short travel distance with these switches, but the absence of a plate does reduce bottoming out noise, and the sound profile also does not have that metallic ping associated with the downstroke.

When I was using a Mac full time, I almost always used a CODE keyboard for all my typing. That lead me to find something better to use with my iPad, and I snagged a Poker II with MX Clear switches. It was a good keyboard for occasional iPad use, but it had a few fatal flaws: it was ugly, and the CMD key was unchangeably in the wrong location.

I had given up on a mechanical keyboard for the iPad when I switched to it full time — I just hated the way all of them looked. However, over the last few weeks I have come back to wanting a better typing experience. I hooked up the CODE and remembered why I loved it so much, but the same problem with the CODE + iPad Pro remains: scale. The keyboard is just too large compared to the iPad Pro.

I needed something smaller.

Pok3r Keyboard

I tried the Poker II again, but just couldn’t be bothered. When I went looking around I found the Vortex Pok3r (aka Poker 3) — an all new and vastly improved version of the Poker II. Still in the 60% layout format.

The changes in the Pok3r are vast: better case, better design, and programmable key layers. With all of these changes, the issues I had with the Poker II are resolved.

Programming

You wouldn’t know the keyboard was programmable when you opened the box, as it comes with no manual. But some searching around and you’ll come across this handy guide for getting your keyboard setup.

I was quickly able to reprogram the keys, however the right CMD reprogram has yet to really work for me — until I realized you also needed to move the FN key — after that everything worked. I’ve been able to fully reprogram the keyboard to work just as I want it to, with one notable exception.

There’s no Eject key — which you think would be a non-issue given that I am using it with an iPad and not a Mac, however the Eject key is how you prompt iOS to show the emoji keyboard. Without it, I am left without access to the keyboard while using the Pok3r.

Overall a much greater success than when I used the Poker II.

Design

For me this is one of the biggest changes. If you look at the two beside each other you can readily see how much better the Pok3r looks. But it also feels much better too. The case is no longer plastic which scales the edges, instead it is a heavy chunk of aluminum which sits low. The key caps too are made of a nicer material, but more than that they don’t have any of the cheesy crap from the Poker II models printed on them.

The entire keyboard looks like a keyboard which has been stripped down to it’s more essential components: the keys. It’s edge to edge keys and I think it looks fantastic (of course you can get aftermarket keycaps to modify the look if you desire).

In Use with iPad Pro

The Pok3r is a wired keyboard, and thus you need to use one of the many “camera connection adapters” for the iPad in order to hook it up. It can be powered off the non-powered kit, but fair warning: it takes a toll on the battery. Without the keyboard attached, just using the Smart Keyboard Cover, I can get about 8-9 hours of battery from my iPad Pro in an average day. With the Pok3r attached, I get 7-8 hours, losing about a full hour of battery life. That’s less than ideal, but can be mitigated with the powered adapter to keep your iPad Pro charged.

Aside from the battery life hit, I’ve found working with this setup to be near perfect. To alleviate the visual eye sore of the wires, I bought better looking wires, yeah. I’ve been using the excellent Compass (version 1, not 2) to prop up the iPad Pro as well.

Once properly programmed, I’ve had no issues at all with using the keyboard and iPad together — far fewer issues than I do when I try to use any Bluetooth keyboard with it.

Note About the Back Light

When I initially received the keyboard the back light made an insane sounding high pitched whine when it was on. Some searching around lead me to find that a firmware update would fix the issue. In order to update the firmware I had to dig out a circa 2002 Dell laptop, but I got the job done and no more whine.

Overall

I was initially worried I would be close, but not there with this keyboard, but I am there. This is a fantastic keyboard, not just for iPad users but for computing in general. I do wish there was a bluetooth version, but I also find Bluetooth keyboards problematic on iOS, so perhaps it’s better not to be given the option.

You can find yours here.
